Our engineers have set the next standard for magnification, imaging performance and mechanical precision. With its 8-40x magnification and unsurpassed resolution, this optic transcends anything you’ve ever seen before.
With an elevation adjustment range of 28mils and a field of view of 4.6m/100m – 1.0m/100m at 40x magnification, you’ll have a substantial image to keep your target in view.
The ZCO 8-40X56 was purposefully designed for the long-range shooting enthusiast that demands the highest level of optical and mechanical performance. With a magnification range of 8-40X, a time-proven 5X erector ratio delivers the needed magnification and superior optical performance.
This optic delivers a higher magnification of 40X for the best view of the target and precise aiming for accurate shot placement. It includes our standard suite of ZCO features such as locking turrets and diopter, Advanced Illumination Management (AIM), and a finely tuned parallax that focuses down to 15 meters for the ultimate in short-range precision.
Shooters engaging in everything from NRL22 style competitions to Extreme Long-Range situations now have a top tier high-magnification optic that’s best suited to their specific shooting requirements.
Highest magnification: 31x-40x
Illuminated Reticle: Yes
Minimum Parallex: 15m-∞
Objective Lens Diameter: 56mm
Reticle Plane: First
Tube Diameter: 36 mm
Turret Click Value: 0.1 MRAD (cm)
- Magnification: 8-40
- Objective: 56
- Main Tube Diameter (mm): 36
- Click Value (MIL): 0.1
- Elevation (MIL): 28
- Elevation (m/100m): 280cm / 100m
- Elevation lock: YES
- Windage (MIL): 16
- Windage (cm/100m): 160cm / 100m
- Windage lock: YES
- Field of View (ft/100yd): 13,8`- 3`
- Field of View (m/100m): 4,6m – 1m / 100m
- Eye Relief (inches): 3.54
- Eye Relief (mm): 90
- Parallax Compensation (m): 15 – ∞
- Length (inches): 17.32
- Length (mm): 440
- Weight (oz): 40.56
- Weight (g): 1150
- Illumination: red | green
- Focal Plane: FIRST
- Light Transmission (%): 92
- Diopter: -3 | +2
- Exit Pupil (mm): 7 – 1.4
